Custom Inline Bevel Helical Worm Gearbox Motor Vertical Flange Mounted
| MOQ: | 1 |
| Price: | negotiation |
| Standard Packaging: | standard export wooden case |
| Delivery Period: | 8-15work days |
| Payment Method: | T/T |
| Supply Capacity: | 100sets per month |
Detail Information
Place of Origin
china
Brand Name
FANBAO
Certification
CE
Model Number
R, RF, RX ,RXF,RM
Gearing Arrangement:
Helical
Output Torque:
50000N.m
Input Speed:
600~1800rpm
Output Speed:
14-280rpm
Weight (KG):
50kg
Warranty:
1 Year
Color:
Customer Requirement
Ratio:
7.5~100
Mounting Position:
Foot-mounted
Installation Form:
Horizontal (foot Mounted) Or Vertical (flange Mounted)
Size:
R17~R167
Input Form:
IEC Flange, Direct With Motor, Shaft Input
Phase:
Single Or Three Phase
Gear Material:
Low Carbon High Alloy Steel
Heat Treatment:
Carburising/quenching/gear Grinding
Highlight:
custom helical worm gearbox
,Vertical helical worm gearbox
,custom helical gears flange mounted
Product Description
Custom Inline Bevel Helical Worm Gearbox Motor Vertical Flange Mounted
Product Specifications
| Attribute | Value |
|---|---|
| Gearing Arrangement | Helical |
| Output Torque | 50000N.m |
| Input Speed | 600~1800rpm |
| Output Speed | 14-280rpm |
| Weight | 50kg |
| Warranty | 1 year |
| Color | Customer Requirement |
| Ratio | 7.5~100 |
| Mounting Position | Foot-mounted |
| Installation Form | Horizontal (foot mounted) or Vertical (flange mounted) |
| Size | R17~R167 |
| Input Form | IEC flange, direct with motor, shaft input |
| Phase | Single or three phase |
| Gear Material | Low carbon high alloy steel |
| Heat Treatment | Carburising/quenching/gear grinding |
Product Description
Our complete range of R Series (two-stage and three-stage) helical gearmotors provides the optimum size and power solution for every drive task. For applications where weight is an issue, our multi-stage gear units offer exceptional efficiency. The die-cast aluminum design of models R07, R17 and R27 makes them particularly lightweight - ideal as satellite drives and for use in light machine constructions. Reduced backlash helical gear units are available for particularly precise requirements.
Structure Options
- R: Shaft extension type foot installation
- RF: Flange installation
- R...F: Foot flange installation
- RM: Flange installation with extended bearing box
- RX: Single-stage foot installation
- RXF: Single-stage flange installation
