High Precision Inline Helical Gear Reducer Gearmotor 132KW

MOQ:	1
Price:	negotiation
Standard Packaging:	standard export wooden case
Delivery Period:	8-15work days
Payment Method:	T/T
Supply Capacity:	100sets per month

Detail Information

Product Description

Detail Information

Place of Origin

china

Brand Name

FANBAO

Certification

Model Number

K KA KF KAF

Gearing Arrangement:

Helical

Output Torque:

50000N.m

Input Speed:

600~1800rpm

Output Speed:

14-280rpm

Weight (KG):

Warranty:

1 Year

Color:

Customer Requirement

Ratio:

7.5~100

Size:

K KA KF KAF KAZ KAT KAB

Efficiency:

Over 95%

Gear Material:

20CrMnTi

Housing Material:

HT250 High-strength Cast Iron

Input Ways:

Motor Input, AM (IEC) Flange Input, And Shaft Input

Output Way:

Solid Shaft Output Or Hollow Shaft Output

Highlight:

High precision Helical Gear Reducer

132KW Helical Gear Reducer

132KW inline helical gear reducer

Product Description

High Precision Inline Helical Gear Reducer Gearmotor 132KW

Product Specifications

Attribute	Value
Gearing Arrangement	Helical
Output Torque	50000N.m
Input Speed	600~1800rpm
Output Speed	14-280rpm
Weight	80kg
Warranty	1 year
Color	Customer Requirement
Ratio	7.5~100
Size	K KA KF KAF KAZ KAT KAB
Efficiency	Over 95%
Gear Material	20CrMnTi
Housing Material	HT250 high-strength cast iron
Input Ways	Motor input, AM (IEC) flange input, and shaft input
Output Way	Solid shaft output or hollow shaft output

Product Overview

The K Series helical-bevel gearmotor combines international manufacturing standards with advanced technology to deliver a space-saving, durable solution capable of withstanding high overload capacities up to 132KW. With energy efficiency exceeding 95%, this gear reducer offers superior performance with minimal energy consumption.

Technical Specifications

Size	37	47	57	67	77	87	97	107	127	157	167	187
Input Power (kW)	0.18-3.0	0.18-3.0	0.18-5.5	0.18-5.5	0.37-11	0.75-22	1.1-30	3-45	7.5-90	11-160	00	18.5
Ratio	5.36-106.38	5.81-131.87	6.57-145.14	7.14-144.79	7.24-192.18	7.19-197.37	8.95-176.05	8.74-141.46	8.68-146.07	12.65-150.41	17.28-163.91	17.27-180.78
Permissible Torque (N.m)	200	400	600	820	1550	2700	4300	8000	13000	18000	32000	50000

Key Features

Serialized and modular design with compact structure and wide transmission ratio range (up to 96% efficiency)
Gears processed through carburizing, nitriding, and grinding for enhanced durability
High efficiency operation with superior performance and minimal energy consumption
Precision-engineered gears ensure stable transmission, low noise, and exceptional load capacity
Multiple installation configurations available for versatile applications

Product Images
